lococube® mini-PLC STG-950

Quantity	Unit price
To 9	€159.00*
To 49	€150.00*
To 99	€139.00*
To 249	€127.00*
From 250	€115.00*

Prices excl. VAT plus shipping costs

Available, delivery time: 2-5 days *

Product number: 0850-0950

Manufacturer: BARTH® Elektronik GmbH

EAN: 4251329406110

Product information "lococube® mini-PLC STG-950 "

Highly flexible mini-PLC for OEM solutions
Connector for customer-tailored AddOn Board
High-Performance 32 Bit ARM® Cortex® M4
3 analog Inputs 0 to 30/0 to 10 VDC, 12 bit ADC
2 digital Inputs up to 25 kHz
4 Solid-State Power Outputs up to 1.5 A
1 Power PWM Output 16 Bit up to 25 kHz
CAN 2.0A/B Interface
CAN FD, CANopen® and SAE J1939 Interface (no native miCon-L support!)
Comprehensive Fail Safe Functions
Open Source ‚C‘ Programming
Wide Operating Voltage Range 7 to 32 VDC
Wide Operating Temp. Range -40 to +70°C
Vibration resistant and rugged Sealing
CE, UKCA, ECE-R10 and RoHS certified
Engineered and manufactured in Germany
Dimensions (LxWxH): 93x45x15mm
Weight: 80g

AddOn Board Functions (Coming soon!)

Current input / output 4-20 mA
Voltage input / output 0-10 V
PT100 / PT1000
Measuring bridges for pressure, weighting, temperature
Galvanically isolated inputs / outputs
Galvanically isolated CAN / CAN-FD bus
RS-232 and RS-485
MODBUS
1-Wire®
IO-Link®

Manual STG-950 [EN]

Sample Programs KEIL® and STM32CubeIDE® for STG-950

Analog Input:	3
Analog Output:	0
CAN Interface:	1
Digital Input:	2
Digital Output:	4
IrDA Interface:	0
PWM Output:	1

Open source programming

New

Connection Cable VK-46

Replaces VK-16 & ST-LINK v2 ISOL + VK-35 for the PLCs listed below!For lococube® miCon-L & open source programmingTTL232 -> USBISP -> USBCompatible with the following BARTH® lococube® mini-PLCs:STG-500, STG-700, STG-800, STG-810, STG-820, STG-850, STG-950, MC-800, GT-800, GT-900, GT-950Incl. STLINK-V3MINIE + USB-C cable (0.3 m) Manua VK-46 (EN)

€59.00*

New

Harness KS-85

You always get right down to business? No time to waste? We hear you! This harness lets you jump straight into development: Easily connect two BARTH-devices to each other and a power supply (sold seperately)CAN lines are properly terminated (60 Ohm) out of the box. The termination resistor can be unplugged easily & reversiblyClip-on connectors allow for easy connection of your own hardware, test equipment or another harness (KS-85 or other)

€69.00*

Details

CANtastic combinations

lococube® mini-PLC STG-800

High-Performance 32 Bit ARM® Cortex®3 analog Inputs 0 to 30 VDC, 12 bit ADCEvent Counter Input 25 kHzPulse and Frequency Counter Input 40µs4 Solid-State Power Outputs up to 1.5 A1 Power PWM Output 16 Bit 1 Hz to 25 kHzCAN 2.0A/B InterfaceCANopen® and SAE J1939 Interface (no native miCon-L support!)Comprehensive Fail Safe FunctionsProgrammable Status LEDTTL-232 3.3V InterfaceIntuitive graphical Programming Capability with miCon-LOpen Source ‚C‘ Programming (Please note that the miCon-L firmware is irreversibly overwritten by “open source” programming and that we cannot release this firmware!)Wide Operating Voltage Range 7 to 32 VDCWide Operating Temp. Range -40 to +70°CVibration resistant and rugged SealingCE, UKCA, ECE-R10, UL, and RoHS certifiedEngineered and manufactured in GermanyDimensions (LxWxH): 60x45x15mmWeight: 50g Manual STG-800/STA-800 (DE) Manual STG-800/STA-800 (EN) Programming Manual miCon-L (EN) Programming Manual KEIL® (EN) Arm Legacy Compiler v5 Guide (EN) Sample Programs KEIL® for STG-800 3D-Data (PDF and STEP)

From €86.00*

Details

lococube® mini-PLC STG-810

Tiny and super-flat CAN Logic ControllerHigh-Performance 32 Bit ARM® Cortex®3 analog Inputs 0 to 30 VDC, 12 bit ADCEvent Counter Input 25 kHzPulse and Frequency Counter Input 40µs4 Solid-State Power Outputs up to 1.5 A1 Power PWM Output 16 Bit 1 Hz to 25 kHzCAN 2.0A/B InterfaceCANopen® and SAE J1939 Interface (no native miCon-L support!)Optical IrDA/SIR Interface (Infrared)TTL-232 3.3V InterfaceComprehensive Fail Safe FunctionsIntuitive graphical Programming Capability with miCon-L Open Source ‚C‘ Programming (Please note that the miCon-L firmware is irreversibly overwritten by “open source” programming and that we cannot release this firmware!)Compatible with PG-65 ProgrammerWide Operating Voltage Range 7 to 32 VDCWide Operating Temp. Range -40 to +70°CVibration resistant and rugged SealingCE, UL und ECE-R10 certifiedEngineered and manufactured in GermanyDimensions (LxWxH): 60x45x15mmWeight: 50g Manual STG-810 (DE) Manual STG-810 (EN) Programming Manual miCon-L (EN) Programming Manual KEIL® (EN) Arm Legacy Compiler v5 Guide (EN) Sample Programs KEIL® for STG-810 3D-Data (PDF and STEP)

From €93.00*

Details

lococube® mini-PLC STG-820

Tiny and super-flat CAN Logic ControllerHigh-Performance 32 Bit ARM® Cortex®3 analog Inputs 0 to 30 VDC, 12 bit ADCEvent Counter Input 25 kHzPulse and Frequency Counter Input 40µs4 Solid-State Power Outputs up to 1.5 A1 analog Output 0 to 5V up to 100kHzCAN 2.0A/B InterfaceCANopen® and SAE J1939 Interface (no native miCon-L support!)Optical IrDA/SIR Interface (Infrared)TTL-232 3.3V InterfaceComprehensive Fail Safe FunctionsIntuitive graphical Programming Capability with miCon-LOpen Source ‚C‘ Programming (Please note that the miCon-L firmware is irreversibly overwritten by “open source” programming and that we cannot release this firmware!)Compatible with PG-65 ProgrammerWide Operating Voltage Range 7 to 32 VDCWide Operating Temp. Range -40 to +70°CVibration resistant and rugged SealingCE, UKCA, ECE-R10, UL und RoHS certifiedEngineered and manufactured in GermanyDimensions (LxWxH): 60x45x15mmWeight: 50g Manual STG-820 (DE) Manual STG-820 (EN) Programming Manual miCon-L (EN) Programming Manual KEIL® (EN) Arm Legacy Compiler v5 Guide (EN) Sample Programs KEIL® for STG-800 3D-Data (PDF and STEP)

From €99.00*

Details

lococube® mini-PLC STG-850

Tiny and super-flat CAN Logic ControllerHigh-Performance 32 Bit ARM® Cortex®6 analog Inputs 0 to 30 VDC, 12 bit ADC4 digital InputsEvent Counter Input 25 kHzPulse and Frequency Counter Input 40µs8 Solid-State Power Outputs up to 1.5 A1 Power PWM Output 16 Bit 1 Hz to 1 kHzCAN 2.0A/B InterfaceCANopen® and SAE J1939 Interface (no native miCon-L support!)IrDA/SIR InterfaceTTL-232 3.3V InterfaceComprehensive Fail Safe FunctionsIntuitive graphical Programming Capability with miCon-LOpen Source ‚C‘ Programming (Please note that the miCon-L firmware is irreversibly overwritten by “open source” programming and that we cannot release this firmware!)Compatible with PG-65 ProgrammerWide Operating Voltage Range 7 to 32 VDCWide Operating Temp. Range -40 to +70°CVibration resistant and rugged SealingCE, UKCA, ECE-R10, UL und RoHS certifiedEngineered and manufactured in GermanyDimensions (LxWxH): 93x45x15mmWeight: 80g Manual STG-850 (EN) Programming Manual miCon-L (EN) Programming Manual KEIL® (EN) Arm Legacy Compiler v5 Guide (EN) Sample Programs KEIL® for STG-850 3D-Data (PDF and STEP)

From €104.00*

Details

lococube® mini-PLC STG-700

2 analog Inputs 0 to 30 VDC, 12 bit ADC2 digital Inputs up to 1 kHz4 Power Outputs up to 1.5 A1 CAN 2.0A/B InterfaceStepper Motor Output 1.5A bipolarReliable Solid-State OutputsFail Safe OscillatorProgrammable Status LEDTTL-232/USB Connection to PCIntuitive graphical Programming CapabilityWide Operating Voltage Range 8 to 32 VDCWide Operating Temp. Range -40 to +50°CVibration resistant and rugged SealingProtection Grade IP 66CE, UKCA, and RoHS certifiedEngineered and manufactured in GermanyDimensions (LxWxH): 58x64x32mmWeight: 180g Manual STG-700 (EN)

From €157.00*

Details

lococube® CAN Display DMA-15

Tiny and compact CAN DisplayColor Touch TFT 2.4“ 240×320pWhite LED BacklightDesign Template Selection via CANNo Programming necessaryOpen Source Programming OptionCompatible with all CAN lococubes®´sFront IP65 Protection Grade (option)Panel-Mount without visible ScrewsPanel Cut-Out (LxW): 60 × 45 mmDimensions (LxW): 69 × 50 mmOperating Voltage 7 to 32 VDCEngineered and manufactured in Germany Manual DMA-15 (EN) Sample Programs miCon-L and KEIL® 3D-Data (PDF and STEP)

From €161.00*

Details

lococube® CAN Display DMA-20

Universal CAN DisplayColor Touch TFT 2.4“ 240×320pLED BacklightDesign Template Selection via CANNo Programming necessaryOpen Source Programming OptionCompatible with all CAN lococube®´sIntegrated Piezo SpeakerFront IP65 Protection Grade (option)Panel-Mount without visible ScrewsPanel Cut-Out (LxW): 106 × 78 mmDimensions (LxW): 115 × 85 mmOperating Voltage 7 to 32 VDCEngineered and manufactured in GermanyDimensions (LxWxT): 115x85x41mmPanel cut-out (LxW): 106x78mmWeight: 200g Manual DMA-20 (EN) Sample Projects miCon-L and C for DMA-15

From €146.00*

Details

lococube® Motor Controller MC-800

Ultracompact CAN Motor ControllerSuitable for all bipolar Stepper Motors up to 2.8ANo Programming necessaryParameter communication via CANDynamic motor current adjustment via CANSpeed and ramps freely configurableStep mode dynamically adjustableOpen-Loop or closed-Loop OperationInputs for Encoder and Limit SwitchesWide Operating Voltage Range 7 to 32VDCCE, UKCA, and RoHS certifiedEngineered and manufactured in GermanyDimensions (LxWxH): 60x45x18mmWeight: 50g Manual MC-800 (EN) Sample Project miCon-L MC-800

From €102.00*

Details

lococube® CAN Gateway GT-900

Ultra compact CAN-FD Gateway2x CAN 2.0A/B / CAN-FD1x RS-2321x 1-Wire®Powerful ARM® Cortex® processorGreat expansion module for all lococube® mini-PLCWide operating voltage range 7 - 32 VDCParameter communication via CANOpen source programmingNo miCon-L supportCE, UKCA, and RoHS certifiedEngineered and manufactured in GermanyDimensions (LxWxH): 60x45x15mmWeight: 50g Manual GT-900 [EN] Sample programs STM32CubeIDE® for GT-900

From €90.00*

Details

lococube® CAN Gateway GT-950

Ultra compact CAN-FD Gateway 2x CAN 2.0A/B / CAN-FD 1x RS-232 1x RS-485 Powerful ARM® Cortex® processor Great expansion module for all lococube® mini-PLC Wide operating voltage range 7 - 32 VDCParameter communication via CAN Open source programming No miCon-L support CE, UKCA, and RoHS certifiedEngineered and manufactured in Germany Dimensions (LxWxH): 60x45x15mm Weight: 50g Manual STG-950 [Manual] Sample Programs STM32CubeIDE® for GT-950

From €93.00*

Details

New

lococube® CAN Gateway GT-960

Ultra compact CAN-FD Gateway 2x CAN 2.0A/B / CAN-FD 1x RS-232 1x RS-485 1x 1-Wire®Powerful ARM® Cortex® processor Great expansion module for all lococube® mini-PLC Wide operating voltage range 7 - 32 VDCParameter communication via CAN Open source programming No miCon-L support CE, UKCA, and RoHS certifiedEngineered and manufactured in Germany Dimensions (LxWxH): 60x45x15mm Weight: 50g Manual GT-960 [EN] Sample Programs STM32CubeIDE® for GT-960

From €97.00*

Details

lococube® IoT Gateway GT-800

Great Expansion Module for all lococube® mini-PLCsNo Programming necessaryParameter Communication via CANSupports CAN/CANOpen®, J1939 and NMEA200Wide Operating Voltage Range 7 to 32VDCCE, UKCA, and RoHS certifiedEngineered and manufactured in GermanyDimensions (LxWxH): 60x45x15mmWeight: 50g Manual GT-800 (EN)

From €101.00*

Details

Mounting

Bracket HA-18 for lococube®

35mm DIN Rail Mounting BracketIdeal for Cabinet MountingBoth horizontal and vertical OrientationSolid PMMA Mounting PlateScrews for lococube® includedSuitable for: STG-850/680 3D Data (PDF and STEP)

€9.50*
