lococube® mini-PLC STG-810

Quantity Unit price
To 9
€127.00*
To 49
€122.00*
To 99
€115.00*
To 249
€105.00*
From 250
€93.00*

Prices excl. VAT plus shipping costs

Available, delivery time: 2-5 days *

Product number: 0850-0810
Manufacturer: BARTH® Elektronik GmbH
EAN: 4251329401320
Product information "lococube® mini-PLC STG-810 "
  • Tiny and super-flat CAN Logic Controller
  • High-Performance 32 Bit ARM® Cortex®
  • 3 analog Inputs 0 to 30 VDC, 12 bit ADC
  • Event Counter Input 25 kHz
  • Pulse and Frequency Counter Input 40µs
  • 4 Solid-State Power Outputs up to 1.5 A
  • 1 Power PWM Output 16 Bit 1 Hz to 25 kHz
  • CAN 2.0A/B Interface
  • CANopen® and SAE J1939 Interface (no native miCon-L support!)
  • Optical IrDA/SIR Interface (Infrared)
  • TTL-232 3.3V Interface
  • Comprehensive Fail Safe Functions
  • Intuitive graphical Programming Capability with miCon-L
  • Open Source ‚C‘ Programming (Please note that the miCon-L firmware is irreversibly overwritten by “open source”
    programming and that we cannot release this firmware!    )
  • Compatible with PG-65 Programmer
  • Wide Operating Voltage Range 7 to 32 VDC
  • Wide Operating Temp. Range -40 to +70°C
  • Vibration resistant and rugged Sealing
  • CE, UL und ECE-R10 certified
  • Engineered and manufactured in Germany
  • Dimensions (LxWxH): 60x45x15mm
  • Weight: 50g

Analog Input: 3
Analog Output: 0
CAN Interface: 1
Digital Input: 2
Digital Output: 4
IrDA Interface: 1
PWM Output: 1

miCon-L & open source programming
